- Main Features:
- Four studio-grade microphone preamps with an ultra-low noise floor, massive headroom, and lightning-fast transient response
- Dante, AES67, and ST2110-ready for seamless integration into IP-based audio networks - or use as a powerful standalone processor
- Remote control from anywhere on your network via an intuitive Windows-based GUI
- Comprehensive processing tools per channel, including:
- 4-band parametric EQ with high/low shelving
- High-pass and low pass filters
- Compressor, limiter, gate
- 31-band graphic EQ
- Specifications:
- Input Interfaces: 4 Analog + 4 Dante
- Output Interfaces: 4 Analog + 4 Dante
- Display: Displays IP Address
- Control Interfaces: 2 X RJ45, 1 X RS232, 1 X RS485
- DSP Processor: TI 456MHz FLOPS Dual-Core 32-bit DSP
- A/D, D/A Conversion: 24-bit, 48kHz Sampling Rate
- Phantom Power: DC 48V
- Input Impedance: 20k ohms, Balanced
- Output Impedance: 100 ohms, Balanced
- Common Mode Rejection Ratio: 52dB @ 50Hz
- Frequency Response 20Hz-20kHz, ±0.15dB
- Noise Floor: -89dBu
- Signal-to-Noise Ratio: 105dB
- THD+N: ≤0.003% @ 1kHz, +4dBu
- Channel Isolation: 100dB @ 1kHz, 4dBu
- Input Range: ≤+18dBu (A-weighted)
- Dimensions (LxWxH): 8 1/2″ × 7 1/2″ × 1 3/4″
- Included extension bar will allow for fitting into a standard 19" rack space
